Model

4M210-06

4M220-06

4M210-08

4M220-08

4M310-08

4M320-08

4M310-10

4M320-10

Media

Air

Action

Internally piloted

Type

5 port 2 position

Orifice size

14mm²(Cv=0.78)

16mm²(Cv=0.89)

25mm²(Cv=1.39)

30mm²(Cv=1.67)

Port size

In=Exhaust=G1/8

In=G1/4

Exhaust=G1/8

In=Exhaust=G1/4

In=G3/8

Exhaust=G1/4

Lubrication

Not required

Pressure range

1.5-8bar(21-114psi)(1.5~8Kgf/cm²)

Max.proof pressure

12bar(170psi)(12Kgf/cm²

Temperature range

-5-60°C(21-140°F)

Voltage range

-15%-+10%

Power consumption

AC:3.5VA  DC:2.5W

Insulation

F class

Protection

IP65(DIN40050)

Connection

Socket with plug

Max.frequency

3 cycles/persee

Min.Activate time

0.05sec.

Weight

220g

320g

220g

320g

310g

400g

310g

400g
